3. ARP OPERATION
3-31
[TRIAL MANEUVER]
1 BACK
2 TRIAL
OFF/STATIC/DYNAMIC
3 TRIAL SPEED RATE
0kt 0.00kt/s
0kt 0.00kt/s
4 TRIAL TURN RATE
0kt 0.0°/s
0kt 0.0°/s
3. Roll the wheel to choose 4 TRIAL MANEUVER and then push the wheel or
the left button.
TRIAL MANEUVER menu
4. Roll the wheel to choose 2 TRIAL and then push the left button or the wheel.
5. Roll the wheel to choose STATIC or DYNAMIC as appropriate and then push
the wheel or the left button.
6. Roll the wheel to choose 3 TRIAL SPEED RATE. Set trial speed rate with the
wheel: Roll the wheel to choose numeral; push the wheel to set.
7. Roll the wheel to choose 4 TRIAL TURN RATE. Set trial turn rate with the
wheel: Roll the wheel to choose numeral; push the wheel to set.
Note: Two sets of trial speed and trial turn rate combinations are provided.
Enter the data by sets as shown in the figure below. This is done to
provide accurate trial maneuver results for various ship’s speed.
3 TRIAL SPEED RATE
4
TRIAL TURN RATE
Set 1
0kt 0.00kt/s
0kt 0.00kt/s
Set 2
Set 1
0kt 0.0
°
/s
0kt 0.0
°
/s
Set 2
8. Push the right button three times to close the menu. Then, the TRIAL box
appears at the right side of the display.
TRIAL OFF
TRIAL box
9. Roll the trackball to choose the TRIAL box and then push the wheel or the
left button to display TRIAL SET. Then, the TRIAL box reads TRIAL SET and
boxes appear above the TRIAL box as below.
86.8°T
06.5kt
00:30
DELAY
TRIAL SET
Course for trial maneuver
Speed for trial maneuver
Delay time for trial maneuver
Trial maneuver status
Boxes for setting trial maneuver parameters
10. Use the wheel to set delay time at DELAY. This is the time after which own
ship takes a new situation, not the time the simulation begins. Change the
delay time according to own ship loading condition, etc. Roll the wheel to
choose location; push the wheel to set.
