Battery Consuming
The device is integrated with a 1000mAH/ 3.7V Li-polymer battery. It can be used for about 3 hours
for GPS function.
The battery icon shows at the right upper corner of the display.
: means the battery capacity is full.
: means the battery capacity is 80% left.
: means the battery capacity is 60% left.
: means the battery capacity is 40% left.
: means the battery capacity is 20% left.
You can also go to Settings/ Power Status item to know the specific percentage of remaining
battery capacity.
Display shows “Low Battery!” message automatically in weak battery status. When battery capacity
leaves 15%, the message will be shown for 2 seconds. However, when electric charge leaves 5%,
the message will keep showing on the screen until the user shuts down or the electricity is run out.
Charging the Battery
Before using your PND for the first time, we recommend you to charge the unit for 5 hours via the
USB cable or 2 hours via the car charger in order to charge the battery.
Plug the USB cable or the car charger into the USB socket .
When you use the PND in your car, we recommend that you always use the car charger in order to
maintain the battery level.
*Disclaimer: some laptops could have insufficient power through the USB port and could lead to
damage your laptop USB port. Binatone Carrera will not be held in any way responsible for the
damages caused to any laptop by charging the device through the laptop USB port
*Charging via USB cable will be faster when the unit is powered off.
When the device is connected to car charger the battery icon will become
. The LED indicator
on the front of the unit will blink in red.
When the battery is fully charged, and the car charger is still connected, the icon will be . And
the LED will be in green color.
Car Adapter
When using your PND in the car we recommend that you always use the in-car charger to power
the unit, especially on long journeys.
Plug the in-car charger into the USB socket of the unit. Plug the other end of the adapter into the
car’s cigarette-lighter / 12V DC socket.
GETTING STARTED
