27
: Tap this icon to switch to North-up mode. Now the map is fixed to keep facing North. The
icon changes to show the new rotation mode.
Tap the icon again to enter Overview mode. This mode looks similar to the North-up mode with one
difference: the zoom level in this mode has a fixed default to give you a better look of where you
are on the map. You can change the zoom level at any time, this will not cause the Follow button to
appear, but when entering Overview mode later, the default zoom level will be restored.
The arrow representing your position will be fixed in the middle of the screen. When you move the
map in Overview mode, the Follow button will appear, and when pushed, it will move the map to
have your current position in the middle of the map again.
You cannot rotate the map in Overview mode. This mode is strictly north-up.
You can set up Binatone Carrera so that it will switch to Overview mode during navigation when the
ed zoom level of Overview in Advanced
An aeroplane icon
indicates Overview mode. Tap the icon again to return to Track-up
(automatic rotation) mode.
No. 11 - GPS position quality
Similarly to the icon found on the GPS Data screen (Page 34), the map screens also inform you
about the GPS signal:
: The black satellite dish with the red exclamation mark shows there is no connection with the
GPS receiver. GPS navigation is not possible. Devices with a built-in GPS receiver are
permanently connected, so this icon may not appear under normal circumstances.
: Red shows there is a connection, but the signal is too weak to give a position. GPS
navigation is not possible.
: Black shows there is a GPS position, and navigation is possible. When only one arc is
shown, the position is 2D (no altitude available), and position error may be significant, yet
ready to navigate.
: A black dish and two arcs represent a 3D GPS position. Binatone Carrera is ready to navigate.
: When small car symbols are displayed under the dish, TMC information is available.
No. 12 - Battery status
The status of the battery is also shown by Binatone Carrera. You can estimate the available power
: The thunderbolt in the battery shows the battery is being charged.
: Battery is not charging, but it is at full capacity.
: Battery in not full, but there is sufficient reserve capacity.
next turn is far away. You can specify this distance and the fix
settings.
Binatone Carrera is
reserve from the length of the bar inside. Some examples:
MAIN ELEMENTS
