Instrument cluster
35
Function Page
8 Multifunction display
with:
150
• Trip odometer
148
• Main odometer
150
9 Tachometer with:
< Seat belt telltale 64,
374
q Preglow indicator
lamp, diesel engine only
129
1 Supplemental
Restraint System (SRS)
indicator lamp
47,
375
± Engine malfunction
indicator lamp, Canada only
379
? Engine malfunction
indicator lamp, USA only
379
Function Page
A High-beam headlamp
indicator lamp
118
a Fuel gauge with:
Fuel tank reserve warning
lamp 378
4 Fuel filler flap
indicator: The fuel filler flap
is located on the rear right-
hand side. 265
b Multifunction display
with:
150
Function Page
• Outside temperature
indicator or digital
speedometer
(depending on selected
setting in the control
system)
153,
159
• Transmission position
indicator
137
• Gear range indicator
139
• LOW RANGE mode
indicator
142
• Distance warning
function indicator
164
• Rear window wiper
indicator
123
• Downhill Speed
Regulator (DSR)
indicator
183
• Off-road driving
program indicator
185
