Mirrors
112
If an exterior rear view mirror housing is
forcibly pushed forward (hit from the rear)
or forcibly pushed rearward (hit from front),
press fold button to fold mirrors in, then
press fold button again to fold mirrors out.
Do not force mirrors by hand as this may
damage the adjustment mechanism.
The mirror housing is then properly
positioned and you can adjust the mirror in
the usual manner.
i
At low ambient temperatures, the exterior
rear view mirrors will be heated
automatically.
Auto-dimming rear view mirrors
The exterior rear view mirror on the driver’s
side and the interior rear view mirror will
respond automatically to glare when the
ignition is switched on and incoming light
from headlamps falls on the sensor in the
interior rear view mirror.
The rear view mirrors will not react if the
automatic transmission is set to reverse gear
R or the interior lighting is switched on.
G
Warning!
The auto-dimming function does not react
if incoming light is not aimed directly at
sensors in the interior rear view mirror.
The interior rear view mirror and the
exterior rear view mirror on the driver’s side
do not react, for example, when
transporting cargo which covers the rear
window.
Light hitting the mirror(s) at certain angles
(incident light) could blind you. As a result,
you may not be able to observe traffic
conditions and could cause an accident.
Power folding exterior rear view
mirrors
!
Before you drive the vehicle through an
automatic car wash, fold in the exterior rear
view mirrors. Otherwise they may get
damaged.
Folding in and out automatically
When the corresponding function in the
control system is activated (Y page 164):
R
The exterior rear view mirrors fold in
automatically as soon as the vehicle is
locked from the outside.
R
The exterior rear view mirrors fold out
automatically as soon as the vehicle is
unlocked and the driver’s or front
passenger door are subsequently opened.
Synchronizing
The power folding rear view mirrors may have
to be synchronized after the vehicle battery
has been disconnected or discharged. If the
exterior rear view mirrors do not fold properly
upon locking or unlocking the vehicle
although the corresponding function in the
control system is activated (Y page 164), do
the following:
X
Fold each exterior rear view mirror in
completely (Y page 113).
X
Fold each exterior rear view mirror out
completely (Y page 113).
When the exterior rear view mirrors fold
properly upon locking the vehicle, the exterior
mirrors are synchronized. Otherwise repeat
the above steps.
Controls in detail
