Seats
103
G
Warning!
To help avoid personal injury when folding
the seat backrest forward, make sure you
move both feet and legs all the way back
and out of the way to avoid them contacting
the seat as it pivots forward.
In order to prevent an accident or any other
potentially dangerous situations when
opening the rear door and exiting the
vehicle, make sure you are aware of the
traffic situation at all times.
X
Open the left door.
X
Exit the vehicle.
Lumbar support
You can adjust the contour of the driver’s seat
lumbar support to help enhance support to
your spine.
1
Curvature up
2
Less curvature
3
Curvature down
4
Greater curvature
X
Curvature position: Use button 1 to
move the curvature up and button 3 to
move it down.
X
Degree of curvature: Use button 2 to
lessen the curvature and button 4 to
increase it.
Rear seats
G
Warning!
According to accident statistics, children
are safer when properly restrained in the
rear seating positions than in the front
seating position. Thus, we strongly
recommend that children be placed in the
rear seats whenever possible. Regardless
of seating position, children 12 years old
and under must be seated and properly
secured in an appropriately sized infant
restraint, toddler restraint, or booster seat
recommended for the size and weight of the
child. For additional information, see
“Children in the vehicle”.
A child’s risk of serious or fatal injuries is
significantly increased if the child restraints
are not properly secured in the vehicle
and/or the child is not properly secured in
the child restraint.
Rear seat adjustment
G
Warning!
Never ride in a moving vehicle with the seat
backrest in an excessively reclined position
as this can be dangerous. You could slide
Controls in detail
Z
