667 Size 80 and 100 Actuators
Instruction Manual
Form 1432
December 2007
20
Key 18 Spring, steel
ACTUATOR
SIZE
RANGE TRAVEL
COMPRESSION
RATE
MAXIMUM
LOAD
PART
NUMBER
COLOR
CODE
SIZE
bar psi mm Inches N/mm Lb/in N Lb
NUMBER CODE
0.2-1 3-15 76 3 175.1 1000 25,042 5630 1H747727082 Red
0.2-1 3-15 51 2
288 9
1650
35 139
7900
1H747527082
Lt Blue
0.3-1.7 5-25 76 3
288.9 1650 35,139 7900 1H747527082 Lt. Blue
80
0.4-2 6-30 38 1.5
367 7
2100
47 148
10 600
1H747327082
Yellow
80
0.4-2 6-30 76 3
367.7 2100 47,148 10,600 1H747327082 Yellow
0.3-1.7 5-25 51 2 455.3 2600 47,148 10,600 1H747627082 Lt. Green
0.2-1 3-15 29 1.125
542 58
3100
61 382
13 800
1H747027082
White
0.4-2 6-30 51 2
542.58 3100 61,382 13,800 1H747027082 White
Key 18 Spring, steel
ACTUATOR
SIZE
COMPRESSION
RATE
MAXIMUM
LOAD
PART
NUMBER
SIZE
N/mm Lb/in N Lb
NUMBER
100
310.8
516.5
787.9
1050.6
1775
2950
4500
6000
77,840
111,200
160,128
200,160
17,500
25,000
36,000
45,000
10A2561X012
10A2562X012
10A2563X012
10A2564X012
Top-Mounted Handwheel Size 100
Key Description Part Number
28 Hex Nut
36 Actuator Stem Extension
41 Gear Case
42 Actuator Stem Connector
43 Thrust Bearing
44 Worm Gear
45 Bearing & Gear Retainer
46 Power Screw Assembly
47 Hex Nut
48 Back Worm Retainer
49 Front Worm Retainer
50 Ball Bearing
51 Worm Shaft
52 Set Screw
53 Gear Case Cover
54 Cap Screw
55 Set Screw
56 Hex Nut
57 Grease Fitting
58 Handwheel
59 Woodruff Key
61 Slot Cover
Hydraulic Snubber Size 80
Key Description Part Number
23 Stem & Piston Assembly
93 Cylinder
94 Cylinder Head
95 Retaining Ring
96* O-Ring, nitrile (2 required) 1F449206992
97* Piston Ring, iron (2 required) 1C710321992
98 Pipe Plug
99 Reservoir
100* O-Ring, nitrile 1H624706992
101 Cap Screw
102 Pipe Plug
103* O-Ring, nitrile (2 required) 1D687506992
104 Adjusting Screw
105 Hex Nut
106 Cap Screw
107* O-Ring, nitrile 1H972406992
108 Hydraulic fluid, 2 gal (7.6L)
109* O-Ring, nitrile (2 required) 1E591406992
110 Orifice
111 Bypass & Check Valve Plug
112 Spring
113 E-Ring
114 Bushing
115 Flange
116 Packing Sleeve
117 Machine Screw
118* Packing, nitrile (8 required) 1P540806992
119* Packing, neoprene & cotton (4 required) 1P540906992
120* O-Ring, nitrile (2 required) 1P541206992
*Recommended spare parts
