667 Size 80 and 100 Actuators
Instruction Manual
Form 1432
December 2007
12
Figure 5. Size 100 Actuator Construction
DIAPHRAGM CASING
COVER (KEY 15)
UPPER DIAPHRAGM
PLATE (KEY 4)
UPPER DIAPHRAGM
CASING (KEY 1)
DIAPHRAGM (KEY 3)
CAP SCREW (KEY 13)
BACK UP PLATE (KEY 6)
HEX NUT (KEY 14)
DIAPHRAGM RETAINER (KEY 5)
LOWER DIAPHRAGM
CASING ASSEMBLY
(KEY 67)
HEX BUSHING (KEY 62)
CAP SCREW (KEY 11)
CAP SCREW (KEY 12)
HEX NUT (KEY 24)
HEX NUT (KEY 241)
WASHER (KEY 37)
O-RING (KEY 240)
SEAL BUSHING
RETAINER (KEY 10)
O-RING (KEY 9)
SEAL BUSHING (KEY 7)
O-RING (KEY 8)
TRAVEL STOP (KEY 12)
HEX NUT (KEY 24)
HEX NUT (KEY 241)
WASHER (KEY 37)
BACK UP PLATE (KEY 6)
DIAPHRAGM PLATE
(KEY 4)
O-RING (KEY 240)
BACK UP PLATE (KEY 6)
UPPER DIAPHRAGM
CASING (KEY 1)
DIAPHRAGM RETAINER
(KEY 5)
CAP SCREW (KEY 13)
DIAPHRAGM (KEY 3)
CASE ADAPTOR
(KEY 245)
CAP SCREW (KEY 13)
DIAPHRAGM BACK UP
PLATE (KEY 246)
DIAPHRAGM (KEY 3)
DIAPHRAGM
RETAINER
(KEY 5)
STANDARD DIAPHRAGM CONSTRUCTION
TOP LOADED DIAPHRAGM CONSTRUCTION
50A2623-F
56A9820-B
C0773-1 / IL
