ACT2000
Power Supply Requirements
A battery power system is recommended, Table 3-5 lists the power supply
requirements.
Voltage: 120VDC nominal
80VDC minimum
160VDC maximum
Max Ripple: 4 VAC RMS or 12VAC p-p
Max Current: 20 AMPS
Typical Continuous Current: <1 AMP
Typical Transient Current: +20 A <60ms
+10A <600 ms
-5A <100 ms
*Output Capacitance: 50,000 uF
*The output capacitance applies for non-battery power systems and assumes full stroke step changes in actuator
position at rated load.
Table 3-5 Power Supply Requirements
3-10
