ACT2000
WARNING:
Property Damage Hazard – Serial inputs are not electrically isolated. Failure
to properly isolate the user serial interface could result in actuator or
computer damage. Use separate conduits for power and signal wiring.
Close proximity to power lines may cause signal interference.
Shock Hazard – The serial inputs are not electrically isolated. If the 120 VDC
power input is floating (not grounded), the serial input connections may
have up to 120 VDC present.
Property Damage Hazard – DO NOT connect 24VDC power to any of the
serial interface connections.
Note: Serial connection limited to 50 ft for local interface only with laptop PC.
3.4.2 Wire Lists
This section will provide ACT2000 wire hook-up information.
Power Harness Electrical Hook-Up
Table 3-3 shows the factory wiring for the ACT2000 power harness.
Wire Color Function AWG
RED Power 14
WHITE/RED Power (AUX) 14
GREEN Power Return 14
WHITE/GREEN Power Return (AUX) 14
Table 3-3: ACT2000 Power Harness Wire List
3-7
