303
Practical hints
Fuses
Fuses
Fuse box in passenger compartment
Opening
̈ Pry cover 1 open with a screw driver or
similar tool.
̈ Remove cover rearward.
Closing
̈ Attach the cover in the front.
̈ Fold the cover in until it engages.
Fuse chart
The fuse chart is found in the fuse box in
the passenger compartment. The amper-
ages of the fuses are also given there.
Fuse box in engine compartment
The fuse box is located in the engine com-
partment on the left-hand side.
1 Cover
2 Screw
3 Retainer
Removing/installing cover
̈ Twist screws 2 90° counterclockwise.
̈ Pull up cover 1.
̈ Slide out retainer 3 and remove cover
by pulling towards front.
̈ Install cover 1 in reverse order.
i
Only install fuses that have been tested
and approved by Mercedes-Benz and
that have the specified amperage rat-
ing.
Never attempt to repair or bridge a
blown fuse. Have the cause determined
and remedied by an authorized
Mercedes-Benz Center.
