151
Controls in detail
Automatic climate control* (Canada only)
Automatic climate control panel
Item
1 Automatic climate control panel
2 Left center air vent, adjustable
3 Right center air vent, adjustable
4 Air volume control for left center air
vent
5 Thumbwheel for adding outside air
6 Air volume control for right center
air vent
7 Air volume control for side air vent
8 Side air vent, adjustable
9 Side defroster vent, fixed
i
For draft-free ventilation, move the slid-
ers for the center air vents to the mid-
dle position.
Item
1 Temperature control, left, raising
2 Left-side air distribution control
(automatic or manual operation)
3 Activated charcoal filter
4 Display
5 Right-side air distribution control
(automatic or manual operation)
6 Temperature control, right, raising
7 Temperature control, right, lower-
ing
8 Rear window defroster
9 AC cooling on/off (AC
OFF
)
Residual heat/ventilation
10 Air volume control
11 Automatic climate control on/off
(complete system)
12 Air recirculation
13 Defrosting
14 Temperature control, left, lowering
