18
passive arming
The system can be programmed to arm automatically. This is
called passive arming. In passive arming mode the system will
arm itself 30 seconds after the user exits the vehicle and closes all
protected entry points.
Passive arming sequence
1. Turn the ignition off and exit the vehicle.
2. Close all protected entry points (doors, hood, trunk).
3. The status LED will blink at twice its normal rate indicating
the system has begun the 30 second countdown.
4. After 20 seconds the siren will chirp once (unless
programmed off) as an audible indication that the system is
about to arm.
5. At 30 seconds the system will fully arm itself. At this time
the lights will flash and the doors will lock (if programmed
for passive locking).
The LED will flash and transceiver’s arm icon (29) will appear and
remain displayed on the LCD. However, the transceiver will not
chirp or vibrate confirmation.
note: The system will not passively arm if a protected entry
or sensor is active; unless forced passive arming has been
programmed on. Refer to the Programming Options section
for information about forced passive arming.
➜
