Replacing bulbs
311
X
Place bulb socket 6 back into the housing
and turn it clockwise until it engages.
X
Align housing cover 1 and turn it clock-
wise until it engages.
High-beam and high-beam flasher bulb
(halogen headlamps)/high-beam
flasher bulb (Bi-Xenon headlamps)
X
Turn housing cover 2 counterclockwise
and remove it.
X
Turn bulb socket 4 with the bulb counter-
clockwise and remove it.
X
Pull the bulb out of bulb socket 4.
X
Press the new bulb gently into bulb socket
4.
X
Place bulb socket 4 back into the housing
and turn it clockwise until it engages.
X
Align housing cover 2 and turn it clock-
wise until it engages.
Front turn signal lamp bulb
X
Turn bulb socket 3 with the bulb counter-
clockwise and remove it.
X
Press gently onto the bulb and turn it coun-
terclockwise out of bulb socket 3.
X
Press the new bulb gently into bulb socket
3 and turn clockwise until it engages.
X
Place bulb socket 3 back into the housing
and turn it clockwise until it engages.
Parking and standing lamp bulb
Halogen headlamps
X
Turn housing cover 2 counterclockwise
and remove it.
X
Pull out bulb socket 5 with the bulb.
X
Pull the bulb out of bulb socket 5.
X
Press the new bulb gently into bulb socket
5.
X
Press bulb socket 5 back into the lamp.
X
Align housing cover 2 and turn it clock-
wise.
Bi-Xenon headlamps
In vehicles with Bi-Xenon headlamps, the
bulbs of the parking and standing lamps are
LEDs.
!
Do not replace the LEDs yourself. You
could otherwise damage the LEDs or parts
of the vehicle. Only have the LEDs replaced
at an authorized Mercedes-Benz Center.
Replacing bulbs for rear lamps
Tail lamp unit
The tail lamps are equipped with HiP bulbs
and LEDs. Have them replaced at an author-
ized Mercedes-Benz Center.
G
Observe Safety notes, see
page 308.
License plate lamps
1
Screws
2
Lamp cover
X
Switch off the ignition.
X
Turn the exterior lamp switch to position
M.
