Controls in detail
Loading
Folding second-row seats
̈ Move the seat to be folded to its rear-
most position (
୴ page 137).
̈ Remove the rear center console*, if so
equipped (
୴ page 308).
̈ Remove the head restraint from the
second-row seat (
୴ page 140).
̈ Place the head restraint on the seat
cushion.
The guide bars must be facing forward.
̈ Push the head restraint against the
seat backrest in direction of the arrow.
1 Seat backrest
2 Seat cushion
3 Release lever
!
When the second-row seats are folded
forward, the front seats may not be
moved to the rearmost position. Other-
wise you could damage the front and
second-row seats.
i
The rear center console* can remain
installed, if installed in the most for-
ward position (
୴ page 309). However,
the cargo compartment floor will then
not be an even plane.
!
Make sure to remove the head restraint
from the seat backrest and place it on
the seat cushion as described before
folding the seat. Otherwise, the seat or
head restraint may be damaged.
୴୴
