Control system
151
Navigation menu
The Navigation menu contains the functions
needed to operate your navigation system.
X
Press button è or ÿ repeatedly until
the Navigation menu appears in the
multifunction display.
The message shown in the multifunction
display depends on the status of the
navigation system:
R
With the COMAND system switched off,
the message NAV off appears in the
multifunction display.
R
With the COMAND system switched on
but route guidance not activated, the
direction of travel and, if applicable, the
name of the street currently traveled on
appear in the multifunction display.
R
With the COMAND system switched on
and route guidance activated, the
direction of travel and maneuver
instructions appear in the multifunction
display.
Please refer to the COMAND system
operating instructions for instructions on how
to activate the route guidance system.
AIRMATIC/Compass menu
The AIRMATIC/Compass menu displays the
AIRMATIC messages and the direction into
which you are currently driving.
X
Press button è or · repeatedly until
one of the following messages appears in
the multifunction display.
Vehicles without AIRMATIC:
Vehicles with AIRMATIC:
For information on AIRMATIC, see
“AIRMATIC” (Y page 166).
For information on the compass, see “Vehicle
submenu” (Y page 158) and
“Compass” (Y page 241).
Vehicle status message memory
menu
Use the Vehicle status message memory
menu to scan malfunction and warning
messages that may be stored in the memory.
Such messages appear in the multifunction
display and are based on conditions or
system status the vehicle’s system has
recorded.
The Vehicle status message memory menu
only appears if messages have been stored.
G
Warning!
Malfunction and warning messages are
only indicated for certain systems and are
intentionally not very detailed. The
malfunction and warning messages are
simply a reminder with respect to the
operation of certain systems. They do not
replace the owner’s and/or driver’s
responsibility to maintain the vehicle’s
operating safety. Have all required
maintenance and safety checks performed
on the vehicle. Bring the vehicle to an
authorized Mercedes-Benz Center to
address the malfunction and warning
messages.
Controls in detail
