N° CATALOGO - CATALOG No. - Nr. CATALOGUE - KATALOG Nr. - N° CATALOGO : 8000 B1247 Pagina emessa Gennaio’08- Page issued January ’08 - Page imprimée Janvier’08 - Seite Herasgegeben Januar’08 - Pagina emitida Enero’08
SMR 450-R / 2008
TAVOLA - DRAWING
TABLE - BILD - TABLA
23
1 8000 B0239 1 Assieme bilanciere Rocking lever assy Balancier compl. Schwinge Kpl. Balancines compl.
3 8000 B0288 2 Spinotto Gudgeon Axe Bolzen Perno
4 8000 B0236 1 Tirante completo Tie rod Tirant Spannstange Tirante
5 8000 B0241 2 Spinotto Gudgeon Axe Bolzen Perno
6 8000 42022 1 Dado Nut Ecrou Mutter Tuerca
8 8000 42781 6 Cuscinetto (ø22xØ26x20 mm) Bearing (ø22xØ26x20 mm) Roulement (ø22xØ26x20 mm) Lager (ø22xØ26x20 mm) Cojinete (ø22xØ26x20 mm)
9 8000 32065 2 Anello di tenuta Seal ring (ø26xØ20x4 mm) Bague de retenue Dichtring (ø26xØ20x4 mm) Anillo de retención
(ø26xØ20x4 mm) (ø26xØ20x4 mm) (ø26xØ20x4 mm)
11 8000 A4431 1 Spinotto D20-d10-L25,2 Gudgeon D20-d10-L25,2 Axe D20-d10-L25,2 Bolzen D20-d10-L25,2 Perno D20-d10-L25,2
12 8000 42023 3 Dado Nut Ecrou Mutter Tuerca
13 8000 B0240 1 Vite (M12x122 mm) Screw (M12x122 mm) Vis (M12x122 mm) Schraube (M12x122 mm) Tornillo (M12x122 mm)
14 8000 32064 1 Cuscinetto Bearing (ø20xØ26x16 mm) Roulement Lager (ø20xØ26x16 mm) Cojinete (ø20xØ26x16 mm)
(ø20xØ26x16 mm) (ø20xØ26x16 mm)
16 8000 32065 2 Anello di tenuta Seal ring (ø26xØ20x4 mm) Bague de retenue Dichtring (ø26xØ20x4 mm) Anillo de retención
(ø26xØ20x4 mm) (ø26xØ20x4 mm) (ø26xØ20x4 mm)
17 8D00 62797 1 Vite (M10x47 mm) Screw (M10x47 mm) Vis (M10x47 mm) Schraube (M10x47 mm) Tornillo (M10x47 mm)
18 8A00 B0240 2 Vite (M12x103 mm) Screw (M12x103 mm) Vis (M12x103 mm) Schraube (M12x103 mm) Tornillo (M12x103 mm)
LEVERAGGI SOSPENSIONE POST. - REAR SUSPENSION LINKAGE
LEVIER SUSPENSION ARRIERE - HEBELWERK HINTERHAUFHANGUNG
PALANCA SUSPENSION TRASERA
