Husqvarna SMR 450-R / 2008 Motorcycle User Manual



47
Note
Notes
Notes
Marke
Notas
Pos.
No.
N.
Index
Pos.
N. Cod.
Code No.
Nr. Code
Code Nr
N. Cod.
Validità
Validity
Validité
Gultig
Validez
DENOMINAZIONE NAME DESIGNATION BESHREIBUNG DENOMINACION
Q.tà
Q.ty
Q.te
M.ge
C.ad
N° CATALOGO - CATALOG No. - Nr. CATALOGUE - KATALOG Nr. - N° CATALOGO : 8000 B1247 Pagina emessa Gennaio’08- Page issued January ’08 - Page imprimée Janvier’08 - Seite Herasgegeben Januar’08 - Pagina emitida Enero’08
SMR 450-R / 2008
TAVOLA - DRAWING
TABLE - BILD - TABLA
CARBURATORE - CARBURETOR
CARBURATEUR - VERGASER
CARBURADOR
13
(KEIHIN)
52 8000 A5635 1 Anello OR O-Ring Anneau OR O-Ring Anillo OR
55 8000 A5636 1 Kit starter (freddo) Starter valve comp. (cold) Kit démarrage (froid) Starter kit (Kälte) Kit arranque (frio)
83 8000 A5637 1 Raccordo Sx L joint comp. Raccord Anschluss Empalme
85 8000 A5638 1 Anello OR O-Ring Anneau OR O-Ring Bague OR
90 8000 A5639 1 Vite regolazione minimo Stop screw idle speed adj. Fil de reglage Reglerkabel Trans. de regulacion
96 8000 A5640 1 Sensore valvola gas Throttle sensor Sensor papillon de gaz Drosselklappesensor Sensòr vàlvula
103 8000 98250 1 Getto aria massimo 200 Main air jet 200 Gicleur d'air principal 200 Hauptluftdüse 200 Surtidor aire màximo 200
122 8000 A5641 1 Anello OR O-Ring Anneau OR O-Ring Bague OR
123 8000 A5642 1 Tappo vaschetta Cap drain Bouchon Verschluss Tapón
148 8000 A5643 1 Tubo Vinyl pipe, bowl vent Tuyau Rohr Tubo
152 8000 A5644 1 Molletta Tube clip Ressort Feder Resorte
206 8000 A5645 2 Tubo Vinyl pipe, bowl vent Tuyau Rohr Tubo
207 8000 A5646 1 Tubo Vinyl pipe, bowl vent Tuyau Rohr Tubo
209 8000 A5647 1 Porta getto Buffer plate Porte gicleur Düsenträger Portachiclè
241 8000 A5648 2 Vite Screw Vìs Schraube Tornillo
243 8000 A5649 1 Molla Coil spring Ressort Feder Resorte
244 8000 A5650 1 Rosetta Collar Rondelle Scheibe Arandela
245 8000 A5651 1 Kit starter (caldo) Starter valve comp. (HOT) Kit démarrage (haut) Starter kit (Wärme) Kit arranque (caliente)
264 8000 A5652 1 Coperchio Cover Couvercle Deckel Tapa
265 8000 A5653 1 Vite Screw Vis Schraube Tornillo
