DENOMINAZIONE NAME DESIGNATION BESHREIBUNG DENOMINACION
Q.tà
Q.ty
Q.te
M.ge
C.ad
N° Catalogo - Catalog No. - Nr. Catalogue - Katalog Nr. - N° Catalogo : 8000
B1247
Pagina emessa Aprile ’08 - Page issued April ’08 - Page Avril '08 - Seite Herasgegeben April ’08 - Pagina emitida Abril ’08
SMR 450-R / 2008
TAVOLA - DRAWING
TABLE - BILD - TABLA
1 2 Vite Screw Vis Schraube Tornillo
2 2 Anello OR O-Ring Bague OR O-Ring Anillo OR
3 2 Vite Screw Vis Schraube Tornillo
4 2 Anello OR O-Ring Bague OR O-Ring Anillo OR
5 2 Tappo Plug Bouchon Verschluss Tapón
6 2 Vite Screw Vis Schraube Tornillo
7 2 Anello OR O-Ring Bague OR O-Ring Anillo OR
8 2 Dado Nut Ecrou Mutter Tuerca
9 2 Anello OR O-Ring Bague OR O-Ring Anillo OR
10 2 Gruppo registro Adjuster set Groupe reglage Kupplungsreglergruppe Grupo regul.
11 80A0 A7584 2 Portastelo completo Pipe assy Groupe tuyau compl. Rohrgruppe Kpl Grupo tubo compl.
12 (a) 4 Bussola Bushing Douille Buchse Manguito
13 2 Scodellino Cup Cuvette Teller Cubeta
14 (b) 2 Anello di tenuta Seal ring Bague de retenue Dichtring Anillo de retención
15 2 Anello di fermo Stop ring Bague d’arrêt Haltering Anillo de retención
16 (b) 2 Raschiapolvere Dust scraper Racloir poudre Pulverabschaber Rascador de polvo
17 8000 B1241 1 Gamba Sx. compl. L.H. fork leg assy Fourche compl. G. Telegabel, Kpl. L. Horquill izrda. compl.
18 8000 B1242 1 Gamba Dx. compl. R.H. fork leg assy Fourche complete D. Telegabel Kpl. R. Horquilla derech. compl.
19 8000 H0817 2 Kit molla (K=4,8 N/mm) Spring (K=4,8 N/mm) Ressort (K=4,8 N/mm) Feder (K=4,8 N/mm) Resorte (K=4,8 N/mm)
21 8000 H0818 2 Gruppo pompante compl. Damping element compl. Amortissement compl. Schwingungsdämpfer Kpl. Bombeadora compl.
23 2 Molla Spring Ressort Feder Resorte
24 2 Asta interna Internal rod Barre Stange Varilla
25 2 Ass. asta Rod assy Barre compl. Stange Kpl Grupo varilla
26 2 Molla Spring Ressort Feder Resorte
27 2 Tampone di fondo Pad Tampon Stopfen Tampòn
28 2 Anello di tenuta Seal ring Bague de retenue Dichtring Anillo de retención
30 2 Lamella Plate Lamelle Plättchen Laminilla
31 2 Segmento Circlip Segment Kolbenring Segmento
32 2 Pistone estensione R.H. piston Piston D. Kolbe R. Pistón der.
33 6 Lamella Plate Lamelle Plättchen Laminilla
20
SOSPENSIONE ANTERIORE - FRONT FORK ASSEMBLY - SUSPENSION AVANT
VORDERTELESKOPGABEL - SUSPENSION DELANTERA
