Note
Notes
Notes
Marke
Notas
Pos.
No.
N.
Index
Pos.
N. Cod.
Code No.
Nr. Code
Code Nr
N. Cod.
Validità
Validity
Validité
Gultig
Validez
DENOMINAZIONE NAME DESIGNATION BESHREIBUNG DENOMINACION
Q.tà
Q.ty
Q.te
M.ge
C.ad
N° CATALOGO - CATALOG No. - Nr. CATALOGUE - KATALOG Nr. - N° CATALOGO : 8000 B1247 Pagina emessa Gennaio’08- Page issued January ’08 - Page imprimée Janvier’08 - Seite Herasgegeben Januar’08 - Pagina emitida Enero’08
SMR 450-R / 2008
TAVOLA - DRAWING
TABLE - BILD - TABLA
1 80B0 B0388 1 Coperchio destro R.H. Cover Couvercle D. R. Deckel Tapa DER.
3 8A00 28855 1 Anello di tenuta Seal ring Bague d'étanchéité Dichtungsring Anillo de retención
(ø12xØ22x6,5 mm) (ø12xØ22x6,5 mm) (ø12xØ22x6,5 mm) (ø12xØ22x6,5 mm) (ø12xØ22x6,5 mm)
4 66N0 21258 1 Anello di fermo Stop ring Bague d'arrêt Haltering Anillo de retención
5 8000 A5906 1 Guarnizione Gasket Garnitue Dichtung Junta
6 8000 99855 1 Anello OR O-Ring Bague OR O-Ring Anillo OR
7 8000 62729 10 Vite (M6X25 mm) Screw (M6X25 mm) Vis (M6X25 mm) Schraube (M6X25 mm) Tornillo (M6X25 mm)
8 8A00 67545 1 Vite (M6X35 mm) Screw (M6X35 mm) Vis (M6X35 mm) Schraube (M6X35 mm) Tornillo (M6X35 mm)
9 8F00 67545 1 Vite (M6X80 mm) Screw (M6X80 mm) Vis (M6X80 mm) Schraube (M6X80 mm) Tornillo (M6X80 mm)
10 8000 73529 1 Oblò Inspection plug Capuchon de inspection Stopfen Portilla
11 8000 B1507 1 Piastrina Plate Plaquette Plättchen Placa
12 8000 07719 2 Bussola Bushing Douille Buchse Manguito
13 80A0 A5934 1 Coperchio frizione Clutch cover Couvercle embrayage Kupplungdeckel Tapa embrague
14 8000 86878 1 Anello OR O-Ring Bague OR O-Ring Anillo OR
15 8000 62730 5 Vite (M6X30 mm) Screw (M6X30 mm) Vis (M6X30 mm) Schraube (M6X30 mm) Tornillo (M6X30 mm)
16 80B0 91551 1 Coperchio filtro olio Oil filter cover Couvercle filtre huile Deckel Tapa
17 8A00 28553 1 Anello OR O-Ring Bague OR O-Ring Anillo OR
18 8000 62728 2 Vite (M6X20 mm) Screw (M6X20 mm) Vis (M6X20 mm) Schraube (M6X20 mm) Tornillo (M6X20 mm)
COPERCHI SEMICARTER DESTRO - R.H. HALF CRANKCASE COVERS
COUVERCLES CARTER D. - GEHAUSEDECKEL R.
TAPAS BANCADA DER.
10
