Note
Notes
Notes
Marke
Notas
Pos.
No.
N.
Index
Pos.
N. Cod.
Code No.
Nr. Code
Code Nr
N. Cod.
Validità
Validity
Validité
Gultig
Validez
DENOMINAZIONE NAME DESIGNATION BESHREIBUNG DENOMINACION
Q.tà
Q.ty
Q.te
M.ge
C.ad
N° CATALOGO - CATALOG No. - Nr. CATALOGUE - KATALOG Nr. - N° CATALOGO : 8000 B1247 Pagina emessa Gennaio’08- Page issued January ’08 - Page imprimée Janvier’08 - Seite Herasgegeben Januar’08 - Pagina emitida Enero’08
SMR 450-R / 2008
TAVOLA - DRAWING
TABLE - BILD - TABLA
1 8000 78442 1 Girante Rotor Couronne Laufrad Rotor
2 8000 42278 1 Dado Nut Ecrou Mutter Tuerca
3 8000 91564 1 Corpo pompa Pump body Corps pompe Pumpenkörper Corpo bomba
4 8000 A4789 1 Albero pompa acqua Water pump shaft Arbre Welle Eje
5 1617 95501 2 Bussola Bushing Douille Buchse Manguito
6 8000 62730 3 Vite (M6x30 mm) Screw (M6x30 mm) Vis (M6x30 mm) Schraube (M6x30 mm) Tornillo (M6x30 mm)
7 8000 27122 1 Anello OR O-Ring Bague OR O-Ring Anillo OR
8 8000 91565 1 Flangia Flange Bride Flansch Brida
9 8000 34317 1 Cuscinetto (ø12xØ28x8 mm) Bearing (ø12xØ28x8 mm) Roulement (ø12xØ28x8 mm) Lager (ø12xØ28x8 mm) Cojinete (ø12xØ28x8 mm)
10 8000 53339 1 Anello di tenuta Seal ring Bague d'étanchéité Dichtungsring Anillo de retención
(ø8xØ16x10 mm) (ø8xØ16x10 mm) (ø8xØ16x10 mm) (ø8xØ16x10 mm) (ø8xØ16x10 mm)
11 8000 40007 1 Anello OR O-Ring Bague OR O-Ring Anillo OR
12 8A00 99708 1 Tubo testa-pompa Pipe Tuyau Schlauch Tubo
13 8B00 99475 2 Fascetta Clamp Collier Schelle Banda
14 8000 99659 1 Radiatore SINISTRO (TOYO) L.H. radiator (TOYO) Radiateur G. (TOYO) L., Kühler (TOYO) Radiador izrdo. (TOYO)
A 14 8000 B1407 1 Radiatore SINISTRO (KTM) L.H. radiator (KTM) Radiateur G. (KTM) L., Kühler (KTM) Radiador izrdo. (KTM)
15 8000 99658 1 Rad. DESTRO compl. (TOYO) R.H. radiator compl. (TOYO) Radiateur D. compl. (TOYO) R., Kühler kpl. (TOYO) Radiador der. compl. (TOYO)
A 15 8000 B1406 1 Rad. DESTRO compl. (KTM) R.H. radiator compl. (KTM) Radiateur D. compl. (KTM) R., Kühler kpl. (KTM) Radiador der. compl. (KTM)
16 8000 A1281 1 Tubazione Hose Tuyau Schlauch Tubo
17 8000 56462 2 Fascetta Clamp Collier Schelle Banda
18 8E00 43716 1 Tubo Pipe Tuyau Schlauch Tubo
19 8000 59803 6 Gommino Rubber pad Pièce caoutchouc Gummistück Junta de goma
20 8000 59802 6 Bussola Bushing Douille Buchse Manguito
21 8000 62728 6 Vite (M6x20 mm) Screw (M6x20 mm) Vis (M6x20 mm) Schraube (M6x20 mm) Tornillo (M6x20 mm)
22 8000 59801 6 Rosetta piana Washer Rondelle Scheibe Arandela
23 8C00 99660 1 Tubo POMPA-RACCORDO Pipe Tuyau Schlauch Tubo
24 8A00 A0669 1 Tubo RAD. SX-RACCORDO Pipe Tuyau Schlauch Tubo
25 8000 B1610 1 Tubo RAD. DX-RACCORDO Pipe Tuyau Schlauch Tubo
26 8000 A0671 1 Raccordo Union Raccord Anschluss Empalme
27 8000 99661 1 Tubo INFERIORE RAD. SX Pipe Tuyau Schlauch Tubo
28 8000 A0779 1 Tubo INFERIORE RAD. DX Pipe Tuyau Schlauch Tubo
29 8A00 99475 4 Fascetta Clamp Collier Schelle Banda
30 8B00 99475 3 Fascetta Clamp Collier Schelle Banda
17
RAFFREDDAMENTO - COOLING SYSTEM
REFROIDISSEMENT - WASSERKUHLUNG
ENFRIAMENTO
