Note
Notes
Notes
Marke
Notas
Pos.
No.
N.
Index
Pos.
N. Cod.
Code No.
Nr. Code
Code Nr
N. Cod.
Validità
Validity
Validité
Gultig
Validez
DENOMINAZIONE NAME DESIGNATION BESHREIBUNG DENOMINACION
Q.tà
Q.ty
Q.te
M.ge
C.ad
N° CATALOGO - CATALOG No. - Nr. CATALOGUE - KATALOG Nr. - N° CATALOGO : 8000 B1247 Pagina emessa Gennaio’08- Page issued January ’08 - Page imprimée Janvier’08 - Seite Herasgegeben Januar’08 - Pagina emitida Enero’08
SMR 450-R / 2008
TAVOLA - DRAWING
TABLE - BILD - TABLA
1 8A00 A7275 1 Ass. carter motore accoppiati Crankcase assy Carter compl. Kurberlgehause kpl. Carter motor completi
2 8000 99846 1 Cuscinetto (ø30xØ72x19 mm) Bearing (ø30xØ72x19 mm) Roulement (ø30xØ72x19 mm) Lager (ø30xØ72x19 mm) Cojinete (ø30xØ72x19 mm)
ALBERO MOTORE CRANKSHAFT VILEBREQUIN KURBEWELLE CIGÜEÑAL
3 8000 97941 2 Piastrina Plate Plaquette Plättchen Placa
4 8A00 55241 3 Vite (M6X14 mm) Screw (M6X14 mm) Vis (M6X14 mm) Schraube (M6X14 mm) Tornillo (M6X14 mm)
5 8000 99847 1 Cuscinetto (ø17xØ40x12 mm) Bearing (ø17xØ40x12 mm) Roulement (ø17xØ40x12 mm) Lager (ø17xØ40x12 mm) Cojinete (ø17xØ40x12 mm)
ALBERO PRIMARIO MAIN SHAFT ARBRE PRIMAIRE HAUPTWELLE EJE PRIMARIO
6 8000 43567 1 Cuscinetto (ø25xØ52x15 mm) Bearing (ø25xØ52x15 mm) Roulement (ø25xØ52x15 mm) Lager (ø25xØ52x15 mm) Cojinete (ø25xØ52x15 mm)
ALBERO SECONDARIO LAYSHAFT ARBRE SECONDAIRE VORGELEGEWELLE EJE SECUNDARIO
7 8000 51746 3 Piastrina Plate Plaquette Plättchen Placa
10 8000 65884 1 Cuscinetto (ø25xØ37x7 mm) Bearing (ø25xØ37x7 mm) Roulement (ø25xØ37x7 mm) Lager (ø25xØ37x7 mm) Cojinete (ø25xØ37x7 mm)
ALBERO COM. FORCELLE GEARBOX GEAR SHAFT ARBRE COMM. FOURCHES ANTRIEBSWELLE EJE MANDO HORQUILLA
CAMBIO SCHALTGABEL CAMBIO
11 8000 34451 1 Anello di tenuta Seal ring Bague d'étanchéité Dichtungsring Anillo de retención
(ø12xØ19x5 mm) (ø12xØ19x5 mm) (ø12xØ19x5 mm) (ø12xØ19x5 mm) (ø12xØ19x5 mm)
12 8A00 65847 1 Bussola Bushing Douille Buchse Manguito
13 8000 59977 1 Anello di tenuta Seal ring Bague d'étanchéité Dichtungsring Anillo de retención
(ø32xØ40x5 mm) (ø32xØ40x5 mm) (ø32xØ40x5 mm) (ø32xØ40x5 mm) (ø32xØ40x5 mm)
14 1610 77703 2 Bussola Bushing Douille Buchse Manguito
15 8000 73500 1 Bussola Bushing Douille Buchse Manguito
16 1610 77601 1 Bussola Bushing Douille Buchse Manguito
17 1614 59002 1 Bussola Bushing Douille Buchse Manguito
18 8000 99850 1 Piastrina Plate Plaquette Plättchen Placa
19 8000 66525 2 Vite Screw Vis Schraube Tornillo
20 8000 91555 1 Pattino catena Chain slider Glissière de chaine Gleitbahn Platode cadena
21 8000 99704 1 Perno Pin Pivot Bolzen Perno
22 8000 99705 1 Piastrina Plate Plaquette Plättchen Placa
23 8000 66774 2 Vite Screw Vis Schraube Tornillo
24 8000 62731 12 Vite (M6X45 mm) Screw (M6X45 mm) Vis (M6X45 mm) Schraube (M6X45 mm) Tornillo (M6X45 mm)
25 8B00 81650 2 Prigioniero (M10x185 mm) Stud bolt (M10x185 mm) Prisonnier (M10x185 mm) Stiftschraube (M10x185 mm) Prisionero (M10x185 mm)
26 8000 A7855 1 Coperchio pignone catena Pinion cover Couvercle pignon Ritzeldeckel Tapa piñón
27 8000 28327 2 Vite M6X14 mm Screw M6X14 mm Vis M6X14 mm Schraube M6X14 mm Tornillo M6X14 mm
28 8000 A0663 1 Piastra guidacatena Plate Plaquette Plättchen Placa
SEMICARTER SINISTRO - L.H. HALF CRANKCASE
CARTER G. - GEHAUSEDECKEL L.
BANCADA IZQ.
8
