5.9 Track
5.9.1 Plotting own ship’s track
A total of 6,000 points are allotted for storage of own ship’s track, marks and
lines. When this memory becomes full, the oldest track is deleted to make room
for the latest. For that reason you may want to adjust the recording interval to
conserve the memory.
The table below shows the relation between plotting interval and maximum track
recording time.
Own track plotting interval and storage time
Interval Max. Recording Time Interval Max. Recording Time
10 s 55 hr 30 min 2 min 27 days 18 hr 40 min
30 s 166 hr 40 min 3 min 41 days 16 hr
1 min 13 days 21 hr 20 min 6 min 83 days 8 hr
1. Roll the trackball to choose the MENU box at the right side of the screen and
then push the left button.
2. Roll the wheel to choose 5 PLOTTER and then push the wheel.
[PLOTTER]
1 BACK
2 CHART COLOR*
GRN/YEL/CYA
ORANGE/GRAY
3 OWN TRACK INTERVAL
OFF/DRAW/10S/30S/
1M/2M/3M/6M/15M
4 OWN TRACK COLOR
RED/GRN/BLU/YEL/
CYA/MAG/WHT
5 TGT TRACK INTERVAL*
OFF/DRAW/10S/30S/
1M/2M/3M/6M/15M
6 TGT TRACK COLOR*
RED/GRN/BLU/YEL/
CYA/MAG/WHT
7 CURSOR L/L ALIGN
OFF/ON
8 [DATA ERASE]
9 [DISPLAY]
0 AUTO TARGET TRACK*
OFF/ON
* Not available on IMO type
PLOTTER menu
3. Roll the wheel to choose 3 OWN TRACK INTERVAL and then push the
wheel or the left button.
4. Roll the wheel to choose appropriate option and then push the wheel or the
left button. Choose OFF to stop plotting own ship’s track. DRAW displays the
track but does not record it.
5. Push the right button twice to close the menu.
