392
Practical hints
Replacing bulbs
Replacing bulbs for front lamps
Before you start to replace a bulb for a
front lamp, do the following first:
̈ Turn the exterior lamp switch to M
(
page 50).
̈ Open the hood ( page 286) (except
for side marker lamps).
1 Headlamp cover for fog lamp
2 Headlamp cover for high beam halogen
headlamp bulb, parking and standing
lamp
3 Headlamp cover for Bi-Xenon* (low and
high beam) or halogen (low beam)
headlamp bulb
4 Bulb socket for fog lamp
5 Bulb socket for parking and standing
lamp
6 Electrical connector for high beam
halogen headlamp bulb
7 Electrical connector for low beam
headlamp bulb
8 Bulb socket for turn signal lamp
Replacing low beam bulbs
Bi-Xenon* headlamp
Warning! G
Do not remove the cover for the Bi-Xenon
headlamp. Because of high voltage in Xenon
lamps, it is dangerous to replace the bulb or
repair the lamp and its components. We rec-
ommend that you have such work done by a
qualified technician.
