193
Controls in detail
Automatic climate control
Item
1 Left center air vent, adjustable
2 Left air vent, fixed
3 Thumbwheel for air volume control
for left center air vent
4 Thumbwheel for air temperature
control for center air vents
5 Thumbwheel for air volume control
for right center air vent
6 Right air vent, fixed
7 Right center air vent, adjustable
8 Side defroster vent, fixed
9 Side air vent, adjustable
a Thumbwheel for air volume control
for side air vents
b Door air vent
c Automatic climate control panel
Warning! G
When operating the automatic climate con-
trol, the air that enters the passenger com-
partment through the air vents in the
footwell can be very hot or very cold (de-
pending on the set temperature). This may
cause burns or frostbite on unprotected skin
in the immediate area of the air vents. Al-
ways keep sufficient distance between un-
protected parts of the body and the footwell
air vents. If necessary change the air flow
using the air distribution controls to direct
the air away from the footwell air vents
(
୴ page 196).
i
For draft-free ventilation, move the slid-
ers for the center air vents 1, 7, 9
to the middle position.
