Controls in detail
Useful features
Ashtrays
Center console ashtray
1 Cover plate
2 Button for disengaging ashtray
Opening ashtray
̈ Briefly touch cover plate 1.
The ashtray opens automatically.
Removing ashtray insert
̈ Secure vehicle from movement by set-
ting the parking brake. Move the gear
selector lever to position N.
Now you have more room to take out
the insert.
̈ Push sliding button 2 to the right.
The ashtray is disengaged and slides
out a short way.
̈ Remove insert from ashtray frame.
Reinstalling the ashtray insert
̈ Install insert by pushing it back into the
frame until it engages.
Rear door ashtray
Opening ashtray
̈ Lightly touch the back of the ashtray.
Removing ashtray insert
̈ Pull the ashtray back slightly and re-
move the insert (see arrows).
Reinstalling the ashtray insert
̈ Position the insert and press down
while sliding forward.
Warning! G
Remove front ashtray only with vehicle
standing still. Set the parking brake to se-
cure vehicle from movement. Move gear se-
lector lever to position N. With gear selector
lever in position N turn off the engine.
