In-dash mounting template for the GlobalMap 5150c, showing
dimensions. NOTE: The figure above is not printed to scale. a scaled
template (FM-5 In-Dash Adapter Kit instructions) is available for free
download from our web site, www.lowrance.com.
Portable Installation
Like many Lowrance products, the GlobalMap 5150c is capable of port-
able operation by using an optional portable power pack (PPP). The
power pack expands the uses for your GPS unit. The PPP makes it easy
to transfer your unit from a boat to a car, recreational vehicle, airplane
or other vehicle without drilling and mounting a second bracket. You
can use your unit in your own car or boat, then take it along when rid-
ing in a friend's vehicle that's not equipped with GPS.
Most LEI portable power packs can be used with eight "D" cell alkaline
batteries. Some use an optional sealed, rechargeable battery. For in-
formation on the PPP for your unit, see the accessory ordering informa-
tion inside the back cover of this manual.
113.5
[4.46]
Millimeters
[Inches]
A
LWAYS VERIFY DIMENSIONS
In-Dash
Template
R 7.9
[0.31]
146.5
[5.76]
Top
