3-5 CRANK TIME 0.6/0.8/1.0/1.2/1.4/1.6/1.8/2.0/4.0 SECONDS: If the unit is programmed for
no engine checking or voltage sense, the crank time must be set to the appropriate duration. The
default setting is 0.6 second. If a different crank time is desired, select feature 3-5 and select either
0.6 second by using the one-chirp setting or toggle through the higher settings by using the two-
chirp settings.
3-6 VOLTAGE CHECK HI/LOW: This feature only functions when programmed for voltage sense.
Some vehicles have many accessories, which are turned on when remote started. In these vehicles,
the variation of voltage between the engine off and the car running is very small and the remote
start unit may "think" the vehicle has not started. This can cause the remote start to shut-down after
the car has been started. If this happens program this feature to the LOW position.
3-7 AUXILIARY OUTPUT FACTORY DISARM/SPECIAL ACCESSORY: In the default setting the
LT. GREEN/BLACK, H2/2, wire sends a negative pulse that may be used to disarm the vehicle’s
factory security system. If programmed for a special accessory, the wire can be used to energize a
relay to power up extra ignition wires in the vehicle. This wire must be used to energize circuits in
the vehicle that operate accessories, such as the radio or heater.
3-8 BLUE WIRE STATUS OUTPUT/FACTORY SECURITY RE-ARM OUTPUT: The blue
(H3/1) wire will supply a 200mA (-) output for the entire remote start run time. If programmed
for factory re-arm output, this wire will supply a momentary 200mA (-) pulse whenever the remote
start times out or is shut down with the transmitter. This can be used to re-arm many factory
security systems.
3-9 AUTOMATIC ANTI-GRIND ON/OFF: With the anti-grind ON (default) the ground-when-
armed output will be active during remote start operation. If accessories such as a voice module or
window module are added to the unit, it may be necessary to program this feature OFF.
Transmitter/Receiver Learn Routine
NOTE: For information regarding transmitter programming please refer to the Owner’s Guide.
The system comes with one transmitter that has been taught to the receiver. The receiver can store
up to four different transmitter codes in memory. Use the following learn routine to add trans-
mitters to the system or to change button assignments if desired.
If the system was previously programmed using the 998T Bitwriter, the learn routine may be
locked. If the siren generates one long chirp when attempting to program the unit, the learn routine
is locked and must be unlocked using the 998T Bitwriter.
1.
OOppeenn aa ddoooorr..
(The H1/5 GREEN wire or the H1/7 VIOLET wire must
be connected.)
