VRX878RVD
English
INSTALLATION
MANUAL
9. SAMPLE SYSTEM
CeNET
STAND
ALONE
SLAVE
STAND
ALONE
(VCZ628)
(DVH943N)
(TTX752/TTX7503z)
(SRK602)
(SRV303)
(DCZ628)
(DAH923)
(NAX963HD)
TV Tuner
CeNET cable
(included
the TV tuner)
RCA video cable
(included the TV tuner)
CeNET DVD Changer
5.1 ch Surround
Decoder
CeNET cable
(included the
DVH943N)
Front
Speakers
4-Channel
Amplifier
Rear
Speakers
Centre speaker
built-in amplifier
Powered subwoofer
built-in amplifier
(Black)
Digital optical fiber cable (included the DVH943N)
RCA cable
(sold separately)
Digital optical fiber cable
(
DCA-005/008, sold separately)
Set the [SLAVE/STAND ALONE]
switch to the [SLAVE] position.
Set the [CeNET/STAND ALONE] switch
to the [CeNET] position.
(Grey)
(Grey)
RCA video cable (included the VCZ628)
Ferrite clamp
(Included the
DVD changer)
RCA cable
(included
the DVH943N)
Red
White
Non fader output
CeNET Cable
(included the Changer)
DAB Tuner
CeNET cable
(included the
DAB tuner)
CeNET Y-adapter
(CCA-519,
sold separately)
CeNET CD Changer
Video
Selector
Yellow
Purple
CeNET cable
(included
the NAX963HD)
HDD Navigation
RGB cable
(included the NAX963HD)
RGB terminal
