INSTALLATION
MANUAL
INSTALLATION AND WIRE
CONNECTION MANUAL
1. BEFORE STARTING
1. This set is exclusively for use in cars with a
negative earth 12 V power supply.
2. Read these instructions carefully.
3. Be sure to disconnect the battery “-” terminal
before starting. This is to prevent short circuits
during installation. (Figure 1)
2. PACKAGE CONTENTS
1 Main unit
2 Manuals
Owner’s manual & Installation manual
Warranty card
3 Power supply lead
4 Rca pin lead
5 Bag for accessories (No. 1)
Flat head screw (M5 u 8)............................. 4
Sems hexagonal bolt (M5 u 8)..................... 5
Electro tap
Machine screw (M4 u 3) .............................. 4
6 Bag for accessories (No. 2)
Hook plate ................................................... 2
Lead clamp
7 Bag for accessories (No. 3)
Rca cap ..................................................... 12
8 Universal mounting bracket
9 Remote control unit
0 Battery
(for remote control unit)
! Outer Escutcheon
@ DCP Case
3. GENERAL CAUTIONS
1. Do not open the case. There are no user-
serviceable parts inside. If you drop anything
into the unit during installation, consult your
dealer or an authorized Clarion service
centre.
2. Use a soft, dry cloth to clean the case. Never
use a rough cloth, thinner, benzine, or alcohol,
etc. For tough dirt, apply a little cold or warm
water to a soft cloth and wipe off the dirt
gently.
Car battery
Figure 1
