TV Operations
61
VRX878RVD
English
Owner’s manual
1. Press the [BAND] button or touch the [Band]
key to select the desired band. (TV1 or TV2)
* If “MANU” is not displayed in the display, keep
pressing the [BAND] button more than 1
second. “MANU” appears and manual tuning is
now available.
2. Tune into a station.
Quick tuning:
Touch and hold the [X] or [x] key for more
than 1 second to tune in a station.
Step tuning:
Touch the [X] or [x] key to manually tune in
a station.
Note:
• Manual tuning is cancelled if you do not operate
the unit for 7 seconds.
Recalling a preset station
A total of 12 TV stations can be stored (6-TV1
and 6-TV2).
There are 2 ways available to recall the preset
station.
●Using the [R] or [F] button
1. Press the [BAND] button or touch the [Band]
key to select the desired TV band. (TV1 or
TV2)
2. Press the [R] or [F] button to recall a
stored TV station.
●Using the Preset List screen
1. Touch the screen to display the menu, then
touch the [List] key.
2. Touch the corresponding Preset key to recall
the stored station.
* You can select the desired band by touching
the [Band] key.
* Touching and holding the desired Preset key
for more than 2 seconds will store the current
station into the preset memory.
3. Touch the [List] key again to return to the
previous screen.
Manual memory
1. Touch the [Band] key to select the desired TV
band. (TV1 or TV2)
2. Tune in the desired TV station to be stored.
3. Touch the [List] key.
4. Touch and hold one of the Preset key for more
than 2 seconds to store the current station into
the preset memory.
Auto store
Auto store selects 6 TV stations automatically
and stores each one into a preset memory. If 6
stations cannot be received with good reception,
previously stored station remain and only the
strong stations are stored into memory.
1. Touch the [Band] key to select the desired TV
band. (TV1 or TV2)
2. Touch the [List] key.
3. Touch and hold the [AS] key for more than 2
seconds.
A beep sounds and the stations with good
reception are stored automatically to the
preset channels.
Preset scan
Preset scan shows each preset channel before it
automatically advances to the next preset. This
function is useful for searching for desired TV
station in memory.
1. Touch the screen to display the TV/VTR mode
menu, then touch the [List] key.
2. Touch the [PS] key to start preset scan. The
unit starts scanning each station for 7
seconds sequentially.
3. When the desired channel is received, touch
the [PS] key again.
Setting the TV diver
You can change the reception setting for the TV
antenna connected to the TV tuner.
* Normally use the TV diver with the “ON” position.
1. Touch the screen to display the TV/VTR mode
menu, then touch the [Option] key.
2. Touch the [ON] or [OFF] key of the TV DIVER
item to turn this function on and off.
[ON]:
Sets reception emphasising the visual.
[OFF]:
Sets the diver setting to OFF.
3. Touch the [Back] key to return to the previous
mode.
Setting the TV area
When you select the TV area (TV reception
area), the TV tuner area setting changes.
1. Touch the screen to display the menu, then
touch the [Option] key.
2. Touch the [TV AREA] key to display a list of
country name.
3. Touch the [c] or [C] key to scroll the list.
4. Touch the desired Country Name key to
select a country.
5. Touch the [Back] key to return to the previous
mode.
