G-PILOT 3100 Installation Manual
NAVMAN
7
2 G-PILOT 3100 hardware
Main unit
Gyro, with 10 m
(33 ft) attached
cable
Protective cover for
display unit
Display unit
Compass, with 10
m (33 ft) attached
cable
Warranty and dis-
play unit mounting
template
This Installation
manual,
Operation manual.
Navman 3100 series wind or speed instrument
using NavBus, then the G-PILOT 3100 will
automatically receive and use the wind or
speed data, and the NMEA connection need
not be wired.
G-PILOT 3100 NMEA outputs
The NMEA 2 port can be confi gured to be an
input or to be output:
Mounting hardware, cable cover,
strain relief, spare fuses
2 mm (#14) twin stranded
cable for high current wiring
Rudder feedback unit
2-1 What comes with your G-PILOT 3100
either heading (HDG & HDT) and rudder
angle (RSA) once per second
or heading (HDG) ten times per second
(see NMEA 2 DAT in the FACTORY menu, See
G-PILOT 3100 Operation Manual).
