When installing the child restraint system,
make sure that the seat belt for the center
seat does not get trapped. Otherwise, the
seat belt could be damaged.
Installation instruction : indicates the
installation point of securing ring
2
.
X
Install the LATCH-type (ISOFIX) child
restraint system. Comply with the
manufacturer's instructions when
installing the LATCH-type (ISOFIX) child
restraint system.
Top Tether
G
Warning
Observe "Important safety notes"
(Y page 55).
G
Warning
Always lock the rear seat backrests in their
upright position when the rear seats are
occupied by passengers. Lock the rear seat
backrests in their upright position before
installing the Top Tether straps or when the
cargo compartment is not in use. Make sure
that rear seat backrests are secured properly
by pushing and pulling on the seat backrests.
If the seat backrest is not locked properly, the
seat backrest could fold forward. The child
restraint system is no longer supported
properly or held in position and can no longer
fulfill its function. This could cause serious or
even fatal injuries.
Top Tether provides an additional attachment
point between the "LATCH" type child seat
mount (ISOFIX) child restraint system and the
rear seat. This can further reduce the risk of
injury.
The Top Tether anchorages are located on the
rear of the rear seat backrests.
X
Move head restraint : upwards.
X
Install the LATCH-type (ISOFIX) child
restraint system with Top Tether. Always
comply with the manufacturer's
installation instructions.
X
Route Top Tether belt A under the head
restraint : between both head restraint
bars.
X
Route Top Tether belt A downwards
between the cargo compartment cover ;
and rear seat backrest.
X
Engage Top Tether hook ? of Top Tether
belt A into Top Tether anchorage =.
Children in the vehicle
59
