Insert the connector.
X
Close the side trim panel (Y page 112).
License plate lamp
X
Switch off the lights.
X
Open the tailgate.
X
Press lug ; of license plate lamp : in the
direction of the arrow and remove license
plate lamp lens :.
X
Remove license plate lamp lens :.
X
Replace the bulb.
X
Insert license plate lamp lens : and press
it in until it engages.
Windshield wipers
Important safety notes
G
Warning!
Wiper blades are components that are subject
to wear and tear. Replace the wiper blades
twice a year, preferably in the spring and fall.
Otherwise the windows will not be wiped
properly. As a result, you may not be able to
observe surrounding traffic conditions and
could cause an accident.
!
Do not operate the windshield wipers
when the windshield is dry, as this could
damage the wiper blades. Moreover, dust
that has collected on the windshield/rear
window can scratch the glass if wiping
takes place when the windshield/rear
window is dry.
If it is necessary to switch on the windshield
wipers in dry weather conditions, always
use washer fluid when operating the
windshield wipers.
!
If the windshield wipers leave smears on
the windscreen after the vehicle has been
washed in an automatic car wash, wax or
other residues may be the reason for this.
Clean the windshield using washer fluid
after washing the vehicle in an automatic
car wash.
Switching the windshield wipers on/
off
Combination switch
1
$ Windshield wipers off
2
Ä Intermittent wipe, low
11
3
Å Intermittent wipe, high
12
4
° Continuous wipe, slow
5
¯ Continuous wipe, fast
B
í Single wipe/ î to wipe the
windshield using washer fluid
X
Switch the ignition on.
X
Turn the combination switch to the
corresponding position.
i
When you stop the vehicle, the wipers
wipe more slowly.
11
Rain sensor set to low sensitivity.
12
Rain sensor set to high sensitivity.
Windshield wipers
113
Lights and windshield wipers
BA 204.9 USA, CA Edition A 2011; 1; 6, en-US
