Remove stowage tray : in the direction of
the arrow.
X
Remove stowage tray ; in the direction of
the arrow.
=
Lug wrench
?
Towing eye
A
Jack
B
Fuse allocation chart
C
Wheel bolts
D
One pair of gloves
E
Ratchet ring spanner
F
Electric air pump
G
Valve extractor
H
Folding wheel chock
Collapsible spare wheel
Removing the collapsible spare wheel
The collapsible spare wheel can be found in
the stowage well under the cargo
compartment floor.
X
Lift the cargo compartment floor up
(Y page 212).
X
Remove stowage well :.
X
Turn retaining screw ; counter-clockwise.
X
Remove collapsible spare wheel =.
X
Take the wheel bolts for the collapsible
spare wheel from the vehicle tool kit.
For further information on changing a wheel
and mounting the spare wheel, see
(Y page 247).
Stowing a used collapsible spare wheel
Take the following steps to stow a used
collapsible spare wheel. It will otherwise not
fit in the spare wheel well. Mercedes-Benz
recommends that you have this work carried
out at a qualified specialist workshop, e.g. an
authorized Mercedes-Benz Center.
!
Only place the collapsible spare wheel in
the vehicle when it is dry. Otherwise,
moisture may get into the vehicle.
X
Remove the valve extractor from the
vehicle tool kit.
X
Unscrew the valve cap from the valve.
X
Unscrew the valve insert from the valve and
release the air.
i
Fully deflating the tire can take a few
minutes.
X
Screw the valve insert back into the valve.
X
Screw the valve cap back on.
