Never fold a windshield wiper arm without
a wiper blade back onto the windshield/
rear window.
Hold the windshield wiper arm firmly when
you change the wiper blade. If you release
the windshield wiper arm without a wiper
blade and it falls onto the windshield, the
windshield may be damaged by the force of
the impact.
Mercedes-Benz recommends that you have
the wiper blades replaced by a qualified
specialist workshop, e.g. at an authorized
Mercedes-Benz Center.
Replacing the windshield wiper blades
Removing the wiper blades
!
Before changing the wiper blades, always
set the wiper arms to a vertical position
using the combination switch. There is
otherwise a risk of damaging the hood.
Moving the wiper arms to a vertical
position
Vehicles without KEYLESS-GO
X
Turn the key to position 1 or 2 in the ignition
lock.
X
Set the windshield wipers to
position ° on the combination switch.
X
When the wiper arms have reached a
vertical position, turn the key to position
0 and remove it from the ignition lock.
Vehicles with KEYLESS-GO
X
Switch off the engine.
X
Take your foot off the brake pedal.
X
Set the windshield wipers to
position ° on the combination switch.
X
Press the Start/Stop button repeatedly
until the windshield wipers start.
X
When the wiper arms have reached a
vertical position, press the Start/Stop
button.
Removing the wiper blades
X
Fold the wiper arm away from the
windshield until it engages.
X
Set the wiper blade at right angles to the
wiper arm.
X
Remove the wiper blade from the retainer
on the wiper arm in the direction of the
arrow.
Installing the wiper blade
X
Slide the new wiper blade into the retainer
on the wiper arm in the opposite direction
to the arrow.
Make sure that the wiper blade slides fully
into the retainer on the wiper arm.
X
Turn the wiper blade parallel to the wiper
arm.
X
Fold the wiper arm back onto the
windshield.
Replacing the rear window wiper blade
G
Warning
The wiper arm could be set in motion and
injure you if the windscreen wipers are
switched on.
Remove the key from the ignition lock before
replacing the wiper blade.
Windshield wipers
115
Lights and windshield wipers
