Folding the rear seat backrest back
:
Backrest
;
Lock verification indicator
=
Backrest release handle
X
Move the driver's or front-passenger seat
forward if necessary.
!
Make sure that the seat belt does not
become trapped when folding the rear seat
backrest back. Otherwise, it could be
damaged.
X
Fold seat backrest : back until it engages.
Red lock verification indicator ; is no
longer visible.
G
Warning!
If a red indicator is visible with the seat
backrest up, then the seat backrest is not
properly locked into position.
Always lock seat backrest in its upright
position when rear seat bench is occupied, or
the expanded cargo volume is not in use.
Check for secure locking by pushing and
pulling on the seat backrest.
In an accident, during hard braking or sudden
maneuvers, loose items will be thrown around
inside the vehicle. This can cause injury to
vehicle occupants unless the items are
securely fastened in the vehicle.
To help avoid personal injury during a collision
or sudden maneuver, exercise care when
transporting cargo.
X
Adjust the head restraints if necessary
(Y page 93).
X
Move the driver's or front-passenger seat
back if necessary.
Securing cargos
Lashing eyelets
Observe the following notes on securing
loads:
R
secure the load using the cargo tie down
rings.
R
do not use elastic straps or nets to secure
a load, as these are only intended as an
anti-slip protection for light loads.
R
do not route tie downs across sharp edges
or corners.
R
pad sharp edges for protection.
There are four cargo tie down rings in the
cargo compartment and two cargo tie down
rings in the rear footwells
24
.
:
Cargo tie down rings in the cargo
compartment
24
Canada only.
Stowage areas
209
Loading, stowing and features
