Cargo tie down rings in the rear footwells
(Canada only)
Bag hooks
!
The bag hook can bear a maximum load
of 11 lbs (5 kg). Do not use it to secure a
load.
There is one bag hook on the left side wall in
the cargo compartment and there are two
hooks on the right and left of the lower D-pillar
trim.
Luggage compartment cover
Important safety notes
!
When loading the vehicle, make sure that
you do not stack the load in the cargo
compartment higher than the lower edge of
the side windows. Do not place heavy
objects on top of the cargo compartment
cover.
The cargo compartment cover is located
behind the rear bench seat backrest.
i
You can fold up the solid section of the
cargo compartment cover approximately
45˚ to facilitate loading the cargo
compartment.
Extending/retracting the luggage
compartment cover
X
To extend: pull cargo compartment
cover : back and clip it into the retainers
on the left and right.
X
To retract: unhook cargo compartment
cover : from the retainers on the left and
right and guide it forwards by the grab
handle until it is fully retracted.
Removing/installing the luggage
compartment cover
X
To remove: make sure that cargo
compartment cover : is rolled up.
X
Press handle ; on the right underside to
the left.
X
Remove cargo compartment cover :.
210
Stowage areas
Loading, stowing and features
