Make sure that the key is in position
1(Y page 129) in the ignition lock.
X
Press on/off switch ; on the electric air
pump to I.
The electric air pump is switched on. The
tire is inflated.
G
Warning
The air hose and the union nut can become
hot during inflation. Exercise proper caution
to avoid burning yourself when using the
equipment.
!
Do not operate the electric air pump for
longer than eight minutes at a time without
a break. It may otherwise overheat.
The air pump can be operated again once
it has cooled down.
X
Inflate the tires to the prescribed tire
pressure.
The prescribed tire pressure is stated on
the yellow sticker which is affixed to
emergency spare wheel.
X
When the prescribed tire pressure has been
attained, press on/off switch 2 on the
electric air pump to 0.
The electric air pump is switched off.
X
Turn the key to position 0 in the ignition
lock.
X
Version 1: if the tire pressure is higher than
specified, open the pressure release screw
on pressure gauge 4 until the correct tire
pressure is set.
X
Version 2: if the tire pressure is higher than
specified, press pressure release button
6 until the correct tire pressure is set.
X
Unscrew union nut A of the air hose from
the valve.
X
Screw the valve cap onto the valve of the
collapsible spare wheel again.
X
Version 1: stow connector = and the air
hose behind flap :.
X
Version 2: stow connector = and the air
hose in the lower section of the pump
housing.
X
Stow the electric air pump in the
designated place in the vehicle.
Lowering the vehicle
G
Warning!
Pump up the collapsible spare wheel before
lowering the vehicle. You could otherwise
damage the wheel rim.
X
Place the ratchet ring spanner onto the
hexagon nut of the jack so that the letters
AB are visible.
X
Turn the ratchet ring spanner until the
vehicle is once again standing firmly on the
ground.
X
Place the jack to one side.
X
Tighten the wheel bolts evenly in a
crosswise pattern in the sequence
indicated (: to A). The tightening torque
must be 110 lb-ft (150 Nm).
G
Warning!
Have the tightening torque checked
immediately after a wheel is changed. The
wheels could come loose if they are not
tightened to a torque of 110 lb-ft (150 Nm).
X
Turn the jack back to its initial position and
store it together with the rest of the vehicle
tool kit in the cargo compartment.
252
Flat tire
