Tires and wheels
220
(Y page 201), make sure the tire inflation
pressure of all four tires is correct.
i
Restart the TPMS after adjusting the tire
inflation pressure to the inflation pressure
recommended for the vehicle operating
condition. Tire pressure should only be
adjusted on cold tires. Observe the recom-
mended tire inflation pressure on the Tire
and Loading Information placard on the
driver’s door B-pillar. Some vehicles may
have supplemental tire pressure informa-
tion for driving at high speeds or for vehicle
loads less than the maximum loaded vehi-
cle condition. If such information is pro-
vided, it can be found on the inside of the
fuel filler flap.
X
Switch on the ignition.
X
Press button è or ÿ on the multi-
function steering wheel repeatedly until the
standard display appears in the multifunc-
tion display (Y page 129).
X
Press button j or k repeatedly until
you see the current inflation pressures for
each tire appear in the display or the fol-
lowing message appears in the display
Tire Pressure Monitor
Active
Menu: R-Button
X
Press the reset button (Y page 124).
The following message will appear in the
multifunction display:
Restart tire
pressure monitor?
X
If you wish to confirm: Press button
æ.
The following message will appear in the
multifunction display:
Tire Pressure Monitor
Restarted
After driving a few minutes the system veri-
fies that the current tire inflation pressures
are within the system’s specified range.
Afterwards the current tire inflation pres-
sures are accepted as reference values and
then monitored.
X
If you wish to cancel: Press button
ç.
Advanced Tire Pressure Monitoring Sys-
tem (Advanced TPMS), (Canada only)
i
This device complies with RSS-210 of
Industry Canada. Operation is subject to
the following two conditions:
1. This device may not cause interference,
and
2. this device must accept any interfer-
ence received, including interference
that may cause undesired operation of
the device.
Any unauthorized modification to this
device could void the user’s authority to
operate the equipment.
The TPMS only functions on wheels that are
equipped with the proper electronic sensors.
It monitors the tire inflation pressure, as
selected by the driver, in all four tires. A warn-
ing is issued to alert you to a decrease in
pressure in one or more of the tires.
G
Warning!
The TPMS does not indicate a warning for
wrongly selected inflation pressures.
Always adjust tire inflation pressure
according to the Tire and Loading Informa-
tion placard or, if available, on the supple-
Operation
