Climate control system
170
1
Thumbwheel
2
Air vent
i
You should keep air vent 2 closed when
outside temperatures are low.
X
Opening the air vent: Make sure air vent
2 is unobstructed.
X
Turn thumbwheel 1 upwards.
X
Closing the air vent: Turn thumbwheel
1 downwards.
AIRSCARF vent
G
Warning!
When switching on the AIRSCARF neck-
level heating, the air streaming from the
openings may be very hot. When in close
proximity to the openings, you could be
seriously burned. To help avoid serious per-
sonal injuries, switch the AIRSCARF to a
lower heating level.
1
AIRSCARF vent
You can switch on the AIRSCARF neck-level
heating with the AIRSCARF switch
(Y page 94).
Adjusting air distribution
The air distribution can be adjusted sepa-
rately on each side of the passenger com-
partment with buttons Ñ.
The symbols on the controls represent the
following functions:
Symbol Function
{
Directs air through the
defroster air vents to the wind-
shield and side windows
a
Directs air through the center
and side air vents
Y
Directs air to the footwells
d
Directs air through the center,
side air vents and to the foot-
wells
[
Directs air through the
defroster air vents to the wind-
shield, side windows and foot-
wells
X
Press one button Ñ until the desired
setting for the respective side of the pas-
Controls in detail
