Wait at least 10 seconds before restarting.
X
Restart the engine.
X
Shift the automatic transmission into drive
position D (for second gear) or reverse gear
R.
X
Have the automatic transmission checked
at an authorized Mercedes-Benz Center as
soon as possible.
Transfer case
For more information on off-road driving, see
“Off-road driving” (Y page 179).
Transfer case position
H HIGH
Road position
L LOW
Off-road position
This position is intended for
driving off-road and step
gradients.
The automatic transmission
will not upshift
automatically to the next
higher gear range when
driving at the rpm limit.
The transfer case supports
the engine’s driving force
(approximately
1
/
2
speed).
Output is therefore
increased.
N Neutral
No power is transmitted
from the engine to the drive
axle.
Switching transfer case
The transfer case switch is located on the
lower part of the center console.
Transfer case switch
Current transfer case indicator : appears in
the multifunction display.
G
Warning!
Always wait until the procedure of shifting
from HIGH to LOW – and from LOW to HIGH
– has been entirely completed. During this
procedure do not turn off the engine or shift
the automatic transmission into another gear.
If you do not wait until the shifting procedure
has been entirely completed then it might not
be correctly performed. The transfer case
might be in neutral, thus interrupting the
transfer of power between the engine and the
drive axle.
The vehicle is then freely movable, even if a
gear has been selected, and could
unintentionally be set into motion –
particularly on up – or downhill grades. This
Transfer case
