such objects at close range and damage to
your vehicle or the object may result.
!
Ultrasonic signals from outside sources
(e.g. truck air brakes, car wash, or
jackhammers) may impair the operation of
the Rear Parking Assist system.
Range of the sensors
Sensors
Center approx. 59 in (150 cm)
Corners approx. 40 in (100 cm)
Minimum distance
Center approx. 8 in (20 cm)
Corners approx. 8 in (20 cm)
If the Rear Parking Assist system detects an
obstacle in this range, all the distance
warning segments illuminate and you hear a
warning signal. If the obstacle is closer than
the minimum distance, the actual distance
may no longer be indicated by the Rear
Parking Assist system.
Warning indicators
Visual signals indicate to the driver the
relative distance between the sensors and an
obstacle.
The warning indicator is divided into four
yellow and two red distance segments :.
The Rear Parking Assist system is ready to
measure when you hear a signal and
readiness indicator ; is illuminated.
As your vehicle approaches an object, one or
more distance segments : will illuminate,
depending on the distance. When the sixth
distance segment illuminates, you have
reached the minimum distance.
An intermittent acoustic warning will sound
when the fourth yellow distance segment
illuminates. This signal quickens with each
additional distance segment lit. When the
sixth distance segment illuminates, the
acoustic warning becomes a constant signal.
The signal is canceled when the automatic
transmission is shifted into drive position D,
or park position P.
116
Driving systems
Controls in detail
