Operation
Tires and wheels
Activating the tire inflation pressure
monitor
You must activate the tire inflation pres-
sure monitor in the following cases:
ț If you have changed the tire pressure
ț If you have replaced the wheels or tires
ț If you have installed new wheels or
tires
̈ Make sure that the tire pressure is cor-
rectly set.
̈ Press button è or ÿ on the mul-
tifunction steering wheel repeatedly
until the standard display menu appear
in the in the multifunction display
(
୴ page 118).
̈ Press the k or j button repeat-
edly until you see the current inflation
pressures for each tire appear in the
display
or the following message appears in
the display
TIRE PRES. MONITOR
PRES. DISPLAY AFTER DRIVING A FEW
MINS. REACTIVATE USING R BUTTON
̈ Press the reset button J (୴ page 22).
The following message will appear in
the multifunction display:
CHECK CURRENT TIRE PRES.?
̈ Press the æ button.
The following message will appear in
the multifunction display field:
TIRE PRES. MONITOR ACTIVATED
The tire inflation pressure monitor will
now monitor the tire inflation pressure
values of all four tires.
The following message will appear in
the multifunction display field:
TIRE PRES. MONITOR
PRES. DISPLAY AFTER DRIVING A FEW
MINS. REACTIVATE USING R BUTTON
This display appears until the individual
inflation pressure values are matched
with the tires. The individual values are
then displayed.
i
If transporting a deflated road wheel or
additional wheel sensors in the vehicle,
the tire inflation pressure monitor
should not be reactivated until the de-
flated wheel or additional wheel sen-
sors have been removed from the
vehicle. Otherwise, the deflated wheel
or additional sensors could cause the
tire inflation pressure monitor system
to malfunction.
