Bettis P/N 124840E
Revision “B”
Page 42 of 46
6.2 G01 TOOL STYLE AND WRENCH SIZE
ITEM
NO.
WRENCH
SIZE
ITEM
QTY
LOCATION OR
DESCRIPTION
RECOMMENDED
TOOL STYLE
1-110 9/16” 4 Hex Cap Screws Socket
1-160 ½” 4 Hex Cap Screws Socket
1-180 3/8” Sq. 2 Stop Screws Open End or Adjustable
1-190 1-15/16” 2 Hex Jam Nuts Open End or Adjustable
3-20 3/8” 2 Tie Bar (flats) Open End or Adjustable
3-40 3/8” Sq. 1 Piston Rod Male Drive
3-90 1-1/8” 2 Standard Hex Nuts Socket
3-100 9/16” 4 Hex Cap Screws Socket
3-120 5/8” Sq. 1 Pipe Plug Open End or Adjustable
3-130 3/16” 2 Socket Cap Screws Allen
5-20 9/16” 4 Hex Cap Screws Socket
7-20 9/16” 4 Hex Cap Screws Socket
12 1” 1 Breather Assembly Socket
13 3/4” 2 Vent Check Assembly Open End
- 3/8” Sq. 1 Tension rod Male Drive
6.3 G2 TOOL STYLE AND WRENCH SIZE
ITEM
NO.
WRENCH
SIZE
ITEM
QTY
LOCATION OR
DESCRIPTION
RECOMMENDED
TOOL STYLE
1-110 9/16” 6 Hex Cap Screws Socket
1-160 9/16” 4 Hex Cap Screws Socket
1-180 3/8” Sq. 2 Stop Screws Open End or Adjustable
1-190 1-1/8” 2 Hex Jam Nuts Open End or Adjustable
3-20 3/8” 2 Tie Bar (flats) Open End or Adjustable
3-40 3/8” Sq. 1 Piston Rod Male Drive
3-90 1-1/8” 2 Standard Hex Nuts Socket
3-100 9/16” 4 Hex Cap Screws Socket
3-120 5/8” Sq. 1 Pipe Plug Open End or Adjustable
3-130 3/16” 2 Socket Cap Screws Allen
5-20 9/16” 6 Hex Cap Screws Socket
7-20 9/16” 4 Hex Cap Screws Socket
12 1” 1 Breather Assembly Socket
13 3/4” 2 Vent Check Assembly Open End
- 3/8” Sq. 1 Tension rod Male Drive
