IN1606 Scaling Presentation Switcher • Internal Web Pages 66
OSD Input Information section
1. To display input information on the OSD bug after input selection, select the Enable On
Screen Display (OSD) check box.
2. In the Duration On Screen field, enter a value or click the Up or Down arrow button to
set a duration the information is displayed on the OSD menu.
NOTE: Enter 0 in the Duration On Screen field to never display the OSD Input
Info. Enter 501 to always display the OSD Input Info bug.
HDCP Notification section
HDCP notification indicates when HDCP content restrictions prevent a video signal from
passing.
• Black — Displays a black or muted screen when an encrypted source is displayed on a
sink that is not HDCP-compliant.
• Green — Displays a green screen when an encrypted source is displayed on a sink that
is not HDCP-compliant (default).
Mute Video and Sync setting
Click the Mute Video and Sync button to mute the active video and disable sync on the
HDMI outputs.
Hardware Pages
The Hardware pages contain unit information and options for device naming,
communication, settings, executive and power modes, date and time settings, passwords,
and reset modes. Click the Hardware tab to open these pages.
Figure 39. Hardware Global Navigation Bar
Unit Information Page
This page gives a non-configurable view of information about the connected device. Click
the Unit Information button to open the page.
The following information is displayed:
• Part number
• Model name
• Model description
• Firmware version
• Temperature
• Device name
• DHCP
• IP address
• Subnet mask
• Default gateway
• MAC address
