IN1606 Scaling Presentation Switcher • SIS Communication and Control 33
Command ASCII Command
(host to scaler)
Response
(scaler to host)
Additional Description
Pixel phase (available only for RGB and YUV input signals)
Specify a value
EX%PHAS} PhasX!*X%] Set the pixel phase to X% on the
current input.
Increment value
E+PHAS} Phas X!*X%]
Increase the pixel phase.
Decrement value
E-PHAS} Phas X!*X%]
Decrease the pixel phase.
View
EPHAS} X%]
View the pixel phase setting.
Total pixels (available only for RGB and YUV input signals)
Specify a value
EX^TPIX} TpixX!*X^] Set the total pixels to X^ on the
current input.
Increment value
E+TPIX} Tpix X!*X^]
Increase the total pixels.
Decrement value
E-TPIX} Tpix X!*X^]
Decrease the total pixels.
View
ETPIX} X^]
View the total pixel setting.
Active pixels
Specify a value
EX&APIX} ApixX!*X&] Set the active pixels to X& on the
current input.
Increment value
E+APIX} Apix X!*X&]
Increase the active pixels.
Decrement value
E-APIX} Apix X!*X&]
Decrease the active pixels.
View
EAPIX} X&]
View the active pixel setting.
Active lines
Specify a value
EX*ALIN} AlinX!*X*] Set the active lines to X* on the
current input.
Increment value
E+ALIN} Alin X!*X*]
Increase the active lines.
Decrement value
E-ALIN} Alin X!*X*]
Decrease the active lines.
View
EALIN} X*]
View the active lines setting.
3:2, 2:2, 24:1 Film mode detect
Auto
EX!*1FILM} FilmX!*X1@]
Set Film mode detection to
automatic (default).
Off
EX!*0FILM} FilmX!*X1@]
Disable Film mode detection.
View setting
EX!FILM} X1@]
View the current Film mode setting.
NOTES:
X! = Input selection 1-6
X% = Pixel phase 0-63 (31 = default)
X^ = Total pixels ±512 of the default value
X& = Active pixels ±512 of the default value
X* = Active lines ±256 of the default value
X1@ = Film detect mode 0 = disable
1 = auto (default)
