Black plate (422,1)
8. Install the coolant reservoir. If you are
unsure of how tight the bolts should be,
have them inspected at an Authorized
Mazda Dealer.
Bolt tightening torque
N·m (kgf·m, ft·lbf)
6.9―11.8
(0.7―1.2, 5.1―8.7)
NOTE
l
To replace the bulb, contact an Authorized
Mazda Dealer.
l
If the halogen bulb is accidentally touched,
it should be cleaned with rubbing alcohol
before being used.
l
Use the protective cover and carton for the
replacement bulb to dispose of the old bulb
promptly and out of the reach of children.
Front side marker lights, Front turn
signal lights
1. Make sure the headlight switch is off.
2. Lift the hood.
3. Remove the attachment bolts and the
coolant reservoir before replacing the
light bulb.
4. Turn the socket and bulb assembly
counterclockwise and remove it.
5. Remove the bulb by pushing it in
slightly and turning it
counterclockwise.
Front side marker lights
Front turn signal lights
6. Install the new bulb in the reverse order
of removal.
7. Install the coolant reservoir. If you are
unsure of how tight the bolts should be,
have them inspected at an Authorized
Mazda Dealer.
Bolt tightening torque
N·m (kgf·m, ft·lbf)
6.9―11.8
(0.7―1.2, 5.1―8.7)
Fog lights
í
1. Make sure the headlight switch is off.
2. Turn the screws counterclockwise and
remove them.
8-40
Maintenance andCare
í
Some models.
Owner Maintenance
CX-9_8V83-EA-06I_Edition3 Page422
Monday, February 26 2007 7:21 PM
Form No.8V83-EA-06I
