Black plate (412,1)
3. Pull down the blade rubber and slide it
out of the blade holder.
4. Remove the metal stiffeners from each
blade rubber and install them in the
new blade.
CAUTION
Don't bend or discard the stiffeners.
You need to use them again.
5. Carefully insert the new blade rubber.
Then install the blade assembly in the
reverse order of removal.
8-30
Maintenance andCare
Owner Maintenance
CX-9_8V83-EA-06I_Edition3 Page412
Monday, February 26 2007 7:21 PM
Form No.8V83-EA-06I
