Page 16 For technical questions, please call 1-800-444-3353. Item 90154
SAFETY OPERATION MAINTENANCEASSEMBLY
Specifications
Maximum Capacity Payload 1,195 lb.
Bed Dimensions 4 Ft. x 8 Ft.
Hitch Ball Size 1‑7/8″
Wheel Rim Diameter/Width 12″x4″
QuantityWheelLugNuts 4 Per Wheel
Tire Size 4.80 - 12
Required Tire Air Pressure 60 PSI, Cold
Overall Dimensions 110″Lx61‑1/2″Wx19‑1/4″H
Ship Weight / Net Weight 262 lb. / 252 lb.
Operating Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this Trailer.
Before each use
1. Check Tire (19) condition and air pressure.
2. Make sure wheel lug nuts/bolts
are properly tightened.
3. Make sure hitch, coupler, draw bar, and other
equipment that connect the trailer and the tow
vehicle are properly secured and adjusted.
4. Make sure wiring is properly connected —
not touching the road, but loose enough to make
turns without disconnecting or damaging the wires.
5. Make sure all running lights, brake lights,
turn signals, and hazard lights are working.
6. Check that all items are securely
fastened on and in the trailer.
7. Be sure the trailer jack, tongue support, and any
attached stabilizers are raised and locked in place.
8. Check load distribution to make sure
the tow vehicle and trailer are properly
balanced front to back and side to side.
9. Check side- and rear-view mirrors to
make sure you have good visibility.
10. Check routes and restrictions on bridges and tunnels.
11. Make sure you have wheel chocks and jack stands.
12. Check trailer for loose bolts and nuts,
structural cracks and bends, and any other
condition that may affect its safe operation.
Do not use the Trailer even if minor damage appears.
